| Product code |
BA.110.04012 |
| Average thrust force @ 10.5V Starting peak force (1.5 sec.) |
40 kfg 65 kfg (peak) |
| Tunnel Diameter |
110mm |
| Electric Motor |
DC series excitation 2.6kW (3.5 hp) 12 V |
| Motor Temperature Protection |
Yes |
| Operation Time Continuous use Intermittent use |
2 minutes/hour 10 minutes |
| Current consumption |
380 A |
| Min. Battery Capacity |
140 Ah |
| Main Fuse (ANL, Slow Blow) |
250 A |
| Battery cable, total length of plus and minus * |
0-9 m / 50 mm2 9-13 m / 70 mm2 |
| Battery terminal connection |
M8 |
| Weight |
11.32 kg |
