Description
Technical data
| Models | 20 HPEP 180 | 20 HPEP 150 | 20HPEP 120 | |||
|---|---|---|---|---|---|---|
| Crankshaft Power [kW] (hp) | 129 (175) | 108 (147) | 88 (120) | |||
| Propeller shaft power [kW] (hp) | 125 (170) | 105 (143) | 85 (116) | |||
| Engine speed [min-1] | 4100 | 4100 | 3800 | |||
| Displacement [I] – (cc) | 2,0 – 1956,5 | |||||
| Number of cylinders | 4 | |||||
| Bore/stroke [mm] (in) | [83,0/90,4] – (3,27/3,56) | |||||
| Compression ratio | 16,5:1 | |||||
| Dry weight without Bravo [kg] [kg] | 290 | |||||
| Emission compliance | Directive 2013/53/UE | |||||
Technical data according to ISO8665. Fuel complies EN590. Merchant fuel may differ in specification and may influence engine power output and consumption. Production tolerance within 5% (of power). Not all models, standard equipment and accessories are available in all countries. All specifications are subject to change without notice.
Standard technical equipment
Engine block and head
Engine mounting
Lubrication system
Fuel system
|
Air inlet and exhaust system
Cooling system
Electrical system
|
Panel instrument CANBUS
Panel Instrument high brightness 5 “TFT display, with touchscreen and a very simple and intuitive interface.
- Engine data acquisition with CANBUS J1939 interface.
- Data acquisition from traditional sensors for up to eight analog inputs, five digital inputs and one frequency input
- Acquisition of navigation data with NMEA0183 interface
- Up to five relay command outputs for signals and simple activations
- Alarm monitoring according to approved safety standards
- Automatic brightness adjustment and day / night mode
- USB local connectivity for firmware update and configuration
The unit is supplied already programmed and ready to work.
Optionals
- Single or double electronic CANBUS control station
- Boiler kit for heating
- Various length panel extension
- Second control panel for flybridge installations
- RACOR and Mediterraneo filters
- Trolling Valve
- Additional PTO (ISO4183 Z/SPZ
- Steering pump
- NMEA2000 compatibility kit
- Wide range of additional instruments
- BRAVO X-1 stern drive Red. 1,65:1 or BRAVO 2 Red.2:1 – BRAVO 3 Red. 2:1
- Stainless steel propeller for BRAVO X-1
- Aluminium propeller for BRAVO X-2
- Stainless steel propeller for BRAVO X-3
- Multiple Sterndrive Steering Tie for twinengine
- Alignment tool
- Volvo coupler kit
