Description
Technical data
| Models | 30 HPEP 270 | 30 HPEP 250 | 30 HPEP 225 | 30 HPEP 180 |
|---|---|---|---|---|
| Max power | 198,5 kW 270 KS 4100 o/min | 184 kW 250 KS 4100 o/min | 165 kW 225 KS 4100 o/min | 132 kW 180 KS 3800 o/min |
| Max. Torque | 530 Nm 2300 rpm | 553 Nm 2600 rpm | 520 Nm 2300 rpm | N.D. |
| Number of cylinders | 4 in line | |||
| Displacement [I] – (cc) | 3 – 2.988 | |||
| Bore and Stroke [mm] – (in) | (95,8×104) – (3,77×4,09) | |||
| Dry weight (kg) | 330 | |||
| Cooling | Water | |||
| Combustion | Direct Injection Common Rail | |||
| Induction | Turbocharged and itercooled | |||
| Emission compliance | Directive 2013/53/UE | |||
Technical data according to ISO8665. Fuel complies EN590. Merchant fuel may differ in specification and may influence engine power output and consumption. Production tolerance within 5% (of power). Not all models, standard equipment and accessories are available in all countries. All specifications are subject to change without notice.
Standard technical equipment
Engine block and head
Engine mounting
Lubrication system
Fuel system
|
Air inlet and exhaust system
Cooling system
Electrical system
|
Panel instrument CANBUS
Panel Instrument high brightness 5 “TFT display, with touchscreen and a very simple and intuitive interface.
- Engine data acquisition with CANBUS J1939 interface.
- Data acquisition from traditional sensors for up to eight analog inputs, five digital inputs and one frequency input.
- Acquisition of navigation data with NMEA0183 interface.
- Up to five relay command outputs for signals and simple activations.
- Alarm monitoring according to approved safety standards.
- Automatic brightness adjustment and day / night mode.
- USB local connectivity for firmware update and configuratio
The unit is supplied already programmed and ready to work.
Optionals
- Boiler kit for heating
- Various length panel extension
- Second control panel for flybridge installations
- RACOR and Mediterraneo filters
- Trolling Valve
- Additional PTO (ISO4183 Z/SPZ
- Steering pump
- NMEA2000 compatibility kit
- Engine Ready to fit to Volvo SX and DPS Stern Drive
