Description
Technical data
| Engine model | 42 HPE 350 | 42 HPE 330 | 42 HPE 300 | 42 HPE 280 | 42 HPE 250 | 42 HPE 150 |
|---|---|---|---|---|---|---|
| Max Power | 257 kW 350 HP 3800 rpm |
242,6 kW 330 HP 3800 rpm |
220,6 kW 300 HP 3800 rpm |
206 kW 280 HP 3800 rpm |
184 kW 250 HP 3800 rpm |
110 kW 150 HP 3800 rpm |
| Max Torque | 700 Nm 71.4 Kgm 2700 rpm |
657 Nm 67 Kgm 2700 rpm |
657 Nm 67 Kgm 2700 rpm |
657 Nm 67 Kgm 2700 rpm |
530 Nm 54 Kgm 2700 rpm |
330 Nm 33.6 Kgm 2700 rpm |
| Number of cylinders | 6 in linea | |||||
| Displacement [I] – (cc) | 4,2 – 4.164 | |||||
| Bore and Stroke [mm] – (in) | [94×100] – (3,7×4,09) | |||||
| Dry Weight [kg] | 460 | |||||
| Cooling | Water | |||||
| Combustion | Direct Injection Common Rail | |||||
| Induction | Turbocharged and intercooled | |||||
| Emission compliance | Directive 2013/53/UE | |||||
Technical data according to ISO8665. Fuel complies EN590. Merchant fuel may differ in specification and may influence engine power output and consumption. Production tolerance within 5% (of power). Not all models, standard equipment and accessories are available in all countries. All specifications are subject to change without notice.
Standard technical equipment
- SAE flywheel housing
- Starter motor 12V – 2,3kW
- Alternator 12V-110A
- Oil and fuel filters
- Air filter
- Freshwater engine cooling system with seawater heat exchanger
- Engine lubricating oil cooled by heat exchanger seawater cooled
- Freshwater cooled exhaust manifold and freshwater tubocharger
- Bronze seawater circulating pump with impeller in special rubber
- Centrifugal pump for freshwater circulation
- Drain oil pump
- Expansion tank integrated
- Stainless steel exhaust gas/seawater mixer
- Flexible mounts
- Electrical instrument panel with alarms
- 8m. panel cable extension
- White paint finish
Panel instrument CANBUS
Panel Instrument high brightness 5 “TFT display, with touchscreen and a very simple and intuitive interface.
- Engine data acquisition with CANBUS J1939 interface.
- Data acquisition from traditional sensors for up to eight analog inputs, five digital inputs and one frequency input.
- Acquisition of navigation data with NMEA0183 interface.
- Up to five relay command outputs for signals and simple activations.
- Alarm monitoring according to approved safety standards.
- Automatic brightness adjustment and day / night mode.
- USB local connectivity for firmware update and configuratio
The unit is supplied already programmed and ready to work.
