Description
General Specs
| POWER SUPPLY | |
| Operating power supply voltage | 22 ÷ 34 VDC / 2 x 15A |
| Power supply | 14V ÷ 36V |
| Idling current | 0,96 A |
| Switched off | 1.6mA |
| Consumption @ 14.4 VDC, 2Ω, Max Musical Power | 27,5 A |
| Remote IN voltage | 6 ÷ 34 V |
| Remote OUT voltage | 14 ÷ 34 VDC |
Audio Specifications
| AMPLIFIER STAGE | |
| Distortion – THD @ 1 kHz, 4Ω, 70% Rated Power | 0,06% |
| Damping factor @ 1 kHz, 4Ω, 2 VRMS | > 110 |
| Bandwidth @ -1.5 dB | 10Hz ÷ 22kHz |
| S/N ratio (A weighted @ 1 V Input) Master Input | 100 dBA |
| S/N ratio (A weighted @ 1 V Input) Optical Input | 105 dBA |
| Input sensitivity Pre-In | 0,6 ÷ 6 VRMS |
| Input sensitivity Speaker-In | 2,2 ÷ 22 VRMS |
| Minimum load impedance | 8Ch: 2Ω |
| 4Ch – (Bridge 1/2; 3/4; 5/6; 7/8) : 4Ω | |
| OUTPUT POWER (RMS) @28.8 VDC, 1% THD: | |
| 8Ch @ 4Ω | 85 W x 8 |
| 8Ch @ 2Ω | 130 W x 8 |
| 4Ch (Bridge 1/2; 3/4; 5/6; 7/8) @ 4Ω | 260 W x 4 |
Digital Signal Processor
| Filter type | Full / High pass / Low pass / Band pass |
| Filter model and | Butterworth (6, 12, 18, 24, 30, 36, 42, 48, 54, 60 dB/oct) Linkwitz-Riley (12, 24, 36, 48, 60 dB/oct) Bessel (6, 12, 18, 24, 30, 36, 42, 48, 54, 60 dB/oct) Chebyshev (6, 12, 18, 24, 30, 36, 42, 48, 54, 60 dB/oct) QLP quasi-linear phase (6, 12 dB/oct) |
| Crossover frequency | 20 Hz – 20000 Hz integer values |
| Phase control | 0 ° – 180°, all pass equalizer poles |
| Output equalizer | Graphic and Parametric modes n. 10 parametric poles (Peaking, High Shelf, Low Shelf, Notch, All pass) ±12 dB gain, variable Q (0.5 – 16.0) n. 10 graphic poles |
| Time alignment distance | 0 – 510 cm (0 – 200.8 inches) |
| Time alignment delay | 0 – 15 ms |
| Time alignment step | 1 cm |
| Time alignment fine set step | 1 sample |
| Memories |
n. 2 memories n. 3 parametric poles for each memory (Peaking, High Shelf, Low Shelf) ±12 dB gain, variable Q (0.5 – 16.0) |
| Preset | Rotary switch for 7 installation presets |
