HMS 12 S4-LD-G

491,00

300 (12) mm (in.) | 191 (7.52) mm (in.) | 4Ω sport led subwoofer | 1000 W | 4 Ohm |Single Voice Coil
The new HMS 12 marine sport grille subwoofer is optimized to perform in open baffle applications for deep and punchy bass without the need to build a dedicated enclosure. HMS 12 is available at 2 or 4-ohm single voice coil versions, featuring a stunning 500 W continuous power handling. The sport grille, featuring built-in LEDs, can be easily and painted the perfect color for your vessel. The motor and suspension design is optimized for high-power, infinite-baffle operation featuring long linear excursion capability for tremendous output with low distortion. Hertz Marine subwoofers not only add tons of bass output to your system but also relieve the main speakers from the hard work of reproducing the lowest frequency range, thus maximizing overall system performance for unlimited sound pressure and emotion!

Categories: ,
Loading...

Description

Technical Specs

Size mm (in.) 300 (12)
Power Handling – Continuous W 500
Power Handling – Peak W 1000
Impedance Ohm 4
Depth mm (in.) 191 (7.52)
Voice Coil Type single
No Filter Component 4Ω SPORT LED SUBWOOFER
Voice Coil Ø 65.5 (2.6)
Magnet size D x d x h mm (in.) 156 x 80 x 40 (6.14 x 3.15 x 1.57)
Weight of one component kg (lb.) 7,6 (16.8)
Magnet High density flux ferrite
Cone Polypropylene with UV inhibitors



Electro-acoustic Specs

D mm 300
Xmax mm 19
Re Ohm 3.3
Fs Hz 30
Le mH 0,62
Vas I 104.7
Mms g 112
Cms mm/N 0,247
BL T*m 8
Qts 1
Qes 1.1
Qms 12.9
Spl dB 89.5
